Specifications +

Range (in): 1/16-1/2 x 64ths
Pack Quantity: 29
Designation: N
Material: High Speed Steel
Finish: Blue
Helix Angle: R30
Point Angle: 118°
Standard: ANSI B94-11

Application +

Optimal for Steel - Non-alloy, cast & free cutting (~ 0.15 %C)- 125 HB
Optimal for Steel - Non-alloy, cast & free cutting (~ 0.45 %C)- 190 HB
Optimal for Steel - Non-alloy, cast & free cutting (~ 0.45 %C)- 250 HB
Optimal for Steel - Non-alloy, cast & free cutting (~ 0.75 %C)- 270 HB
Optimal for Steel - Low alloy & cast < 5% of alloying elements- 180 HB
Optimal for Steel - Low alloy & cast < 5% of alloying elements- 275 HB
Optimal for Steel - High alloy, cast & tool- 200 HB

Features & Benefits +

118° standard point for general purpose applications
Precision engineered parallel shank for accurate hole size
Made from M2 High Speed Steel (HSS) offering the best combination of strength, heat & wear resistance
Blue surface finish for ferrous applications
The steam oxide finish prevents chip build-up on the cutting edges and reduces cutting friction, especially in low carbon steels

Payment & Security

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Save 30%

Sutton D102S8 29 piece Blue Bullet Imperial Jobber Drill Set HSS

SKU: A0003270

Type: Jobber Drill Bit

$230.39

$230.39 ~~$329.13~~

Inc. GST

🔧High Speed Steel Construction

⚙Sutton piece Blue Bullet

📐Supplied as 29 Piece

🔩Accurate Drilling Performance

🏗Metalworking & Manufacturing

☑High Speed Operation Rated

Available

Product Highlights −

Sutton Tools Blue Bullet jobber drills are a general purpose drill bit designed for machine and hand held drilling ferrous metals

The blue finish reduces chip build up on the cutting edge and is a better choice when drilling ferrous materials
