Alemlube 240V Oil Drum Pump

• The 303100 240V high flow oil transfer pump is a self-priming electric vane pump capable of flow rates of up to 50 L/min.
• Manufactured in Italy by Piusi, the 303100 is designed for high flow oil transfer applications in a wide range of transport, industrial, manufacturing, agricultural and infrastructure applications where only 240V power is available.
• With its cast iron impellar and heavy duty robust construction, the pump can operate continuously under a 240V single phase power source and can reach a maximum working pressure of 71psi (5 bar) and offers reliable service while pumping fluids of a viscosity up to 500 cSt.
• The 303100 high flow oil transfer pump available from Alemlube features an asynchronous closed self-ventilating AC motor incorporating sintered steel rotors with resin vanes.
• Installation via the 1” BSPF inlet and outlet threaded ports can be performed simply and effectively in a variety of locations to suit individual needs.

Specification

• Delivery rates of up to 50L/min
• Self-priming 240V electric pump with on/off switch
• Maximum working pressure of 71psi (5bar)
• 1" BSPT inlet & outlet flanged connections
• Voltage: 1,350/1,600 power watt
• Amp max: 6.2
• Noise levels below 70dB
• Weight: 14.1kg
