Angular Contact Ball Bearing 2RS (with Seals) Metric - JAF

Description

Angular Contact Ball Bearing 2RS (with Seals) Metric

Metric.
2RS (with seals).

All About Angular Contact Ball Bearings

Angular contact ball bearing supporting combined radial and bidirectional thrust loads ball contact angle of 20 degrees relative to the inner and outer raceways increases thrust load capacity steel shields on both sides of the bearing to keep lubricant in and contaminants out.
Pressed steel cage evenly spaces balls for reduced friction, vibration, and noise Normal axial internal clearance for applications where thermal expansion is not a factor.

Specifications

AIMS SKU A0156767

Brand JAF

Model Number 5207-2RS/JAF

Bore Diameter (mm) 35

Width (mm) 27

Outer Diameter (mm) 72

Limiting Speed (r.p.m) 5500

Load Rating (kgf) Cr 3100

Load Rating (kgf) Cor 2400

Type Angular Contact Bearings
Series 5200
