Beaver Brake Hand Winches

Description

Beaver Brake Hand Winch

Beaver Brake Hand Operated Winches are a cost effective, versatile solution for a variety of applications.
They can be used for both pulling and lifting applications.
Often referred to as crank winches, they are easy to carry and use.

Product Features

High precision construction minimises gear noise.
Positive load actuated brake can hold the load in any position.
Lightweight, yet durable.
Mechanical components enclosed for protection and safety.
Heat-treated gears.
Strong removable handles.

Specifications

AIMS SKU A0102760

Brand Beaver

Model Number BHW1800

Barcode Number 9322297019116

Gear Ratio 0.209027777777778

Handle Length (mm) 320

Weight (kg) 8

Rated Capacity-pulling (kg) 820

Rated Capacity (hoist) 410

Type of Brake Double Paw

Unit Weight - Bare (kg) 8

Wire Rope Diameter (mm) 6

Wire Rope Construction 7x19 RHOL

Grade of Wire Rope G2070

Wire Rope Finish Galvanised

Wire Rope Storage Capacity (m) 26

Rated Capacity - Pulling (kg) (kN) 820/8.04

Rated Capacity - Hoisting (kg) 410

Max Hand Force Req. (kg) 22

Hub Diamater (mm) 70

Type Brake Hand Winch
