Bossweld Torch Fume Extraction Unit

• Designed to significantly reduce exposure to harmful welding fumes directly at the source.
• Specialized extraction system that efficiently draws in fumes directly from the torch head, minimizing exposure to harmful pollutants, providing a safer and healthier welding environment.

Features

• Easy Connect with Fume Extraction MIG Torches
• Digital Display
• Air Volume Adjustment
• Replaceable Cartridge
• 360° Swivel Casters

Specifications

• Filter Material: PET
• Fittable Fume Size: 0.3 μm
• Filterability: 99.90%
• Filter Cartridge: Ø 230 x 176 mm
• Filter Area: 6 m2
• Control System: Delixi
• Aspirating Volume: 200+10m³/h
• Motor Power: 1.2 kW
• Power Supply: 240V/50Hz
• Blower Loading Pressure: 26000 Pa
• Dust Outlet Diameter: 50 mm
• Air Compression: 0.5~0.6 Mpa
• Noise dB: ≤70±5 dB (A)
• Smoke Removal Method: Manual
• Smoke Cartridge Volume: 5L
• Dimensions: 600 x 285 x 527 mm
• Weight: 24 kg
