Specifications
- AIMS SKU A0156188
- Brand IKO
- Model Number CF3FBUU/IKO
- D1 (mm) 3
- Width (mm) 7
- rs min (mm) 0.2
- Mounting Dimension f Min. (mm) 6.8
- Maximum Allowable Static Load (n) 384
- Maximum Tightening Torque (n-m) 0.34
- B2 (mm) 9
- Roller Diameter 10 mm
- Stud Diameter 3 mm
- B1 (mm) 17
- Basic Static Load Rating C0 (N) 1020
- Basic Dynamic Load Rating C (N) 1500
- Roller Width 7 mm
- Outside Diameter (mm) 10
- H (mm) 2
- g1 (mm) 5
- g (mm) M3 x 0.5
- b (mm) 8
- C1 (mm) 0.5
- Type Cam Follower
- Material Stainless Steel
SKU: A0156188
IKO Cam Follower Stainless Steel Hex 2RS Cylindrical Outer Ring 3 x 10 x 7mm
Cam Follower Stainless Steel 2RS Cylindrical Outer Ring
$143.44
