Description

Technical Information

  • Wheel Diameter: 100 mm
  • Tread Width: 30 mm
  • Load Capacity: 220 kg
  • Overall Height: 131 mm
  • Tyre Material: High Temp Synthetic Monolithic
  • Mounting: Plate
  • Plate Size: 100 mm x 85 mm
  • Hole Centers: 80 mm x 60 mm
  • Bearing Type: Plain
  • Finish: Stainless Steel

Descriptions

  • Suitable for a variety of heavy-duty applications in waste bin, mining, construction, military, airports, warehousing and many other industries
  • Extremely hard wearing, they roll well even on relatively soft surfaces and will not mark floors
  • Resistant to water, most solvents, oils, acids, chemicals and has excellent fire-smoke toxicity properties
  • Certified for use in the food industry and for any oven application requiring continuous exposure to temperatures up to +280°C with peaks of + 300°
  • Permanent lubrication approved by FDA-USDA for contact with foods
  • Computerized control of swivel head double ball race and assembling tolerances assures perfect swiveling without locking point
  • RoHS - REACH compliant

Application

  • Use in freezers, they can be exposed to temperatures as low as -40°C and are resistant to thermal shock due to rapidly rising or falling temperatures

Specifications

  • AIMS SKU A0049507
  • Brand EasyRoll
  • Model Number S32ASSTW100
  • Barcode Number 9315570901765
  • Type Swivel Plate Castor
  • Wheel Diameter (mm) 100
  • Motion Swivel
  • Colour Black
  • Capacity (kg) 220
  • Tread Width (mm) 31 - 40
  • Frame/Hub Material Zinc Plated Pressed/Welded Steel
  • Bearing Type Plain Bearing
  • Indoor Use Yes
  • Outdoor Use Yes
  • Plate Size (mm) 100 x 85
  • Working Height (mm) 131
  • Finished Height (mm) 121 - 140
  • Hole Centres (mm) 80 x 60
  • Tyre/Wheel Material Synthetic Monolithic
  • Special Feature High Temperature
  • Weight Category 200kg - 299kg
SKU: A0049507

100mm Zinc Swivel Plate Castor - High Temp Wheel S3

EasyRoll High Temp Swivel Plate Castor Stainless Steel

$106.79
