Specifications

AIMS SKU A0177850
Brand EZO
Model Number 689-ZZC3/EZO
Cage Type J
Ball Complement Qty Z (pcs) 11
Width B1 (in) 0.197
Width B1 (mm) 5.0
Width B (in) 0.158
Bore Diameter d inch 0.354
Bore Diameter d mm 9.0
Weight (Reference) 2 Shields (g) 4.12
Ball Complement Size Dw (in) 0.079
Ball Complement Size Dw (mm) 2
Bore Diameter x Outer Diameter x Width (mm) 9 x 17 x 5
Max Speed Oil (x1000min -1) 44
Max Speed Grease (x1000min -1) 37
Chamfer rs (min) (in) 0.008
Chamfer rs (min) (mm) 0.20
Outer Diameter D (in) 0.669
Load Rating Cor (N) 664
Load Rating Cr (n) 1330
Width B (mm) 4.0
Outer Diameter D (mm) 17.0
• Type Ball Bearing
• Series Type 680 Series
