FYH H200 Series Bearing Adapter Sleeve Metric

Description

FYH H200 Series Bearing Adapter Sleeve Metric

Metric.
Proper assembly of adapter sleeves can create excellent holding power on the shaft.

***Catalogue Dimensions are Reference Only. Contact AIMS to confirm actual measurement if a specific dimension is critical to your application.***

Specifications

AIMS SKU A0201248

Brand FYH

Model Number H206/FYH

Net Weight (kg) 0.1

Bore (mm) 25

B1 (mm) 27

B2 (mm) 8

(d1) mm 25

(d2) mm 45

Matched Locking Nut KM6

Matched Locking Washer MB6

Type Adaptor Sleeve
System Measurement Metric

Calculate Shipping

Resources

Technical Data Sheet
