Description

High Feed Milling Insert MM4500 Grade (M07 Geometry)

  • MM4500 grade.
  • M07 geometry.
  • 3 cutting edge, single-sided insert.
  • 218.19-125 Insert Seat Size Code (SSC).

About MM4500 Grade

  • CVD coated grade.
  • The extremely tough grade for duplex stainless steel.
  • It can also be used for a wide range of materials when cutting conditions are unstable.

Specifications

  • AIMS SKU A0121863
  • Brand Seco
  • Model Number 02744585
  • Barcode Number 44585027001000
  • Designation 218.19-125T-T3-M07,MM4500
  • Grade Type Carbide CVD
  • Cutting Edge Count (CEDC) 3
  • Insert Hand (IH) Both
  • Insert Thickness (S) mm 3.97
  • Corner Radius (RE) mm 0.8
  • Inscribed Circle Diameter (IC) mm 8.9
  • Clearance Angle Major (an) Deg 12.0 deg
  • Curved Cutting Edge Radius (CCER) mm 12.5
  • Type Milling Insert
  • Grade MM4500
  • Insert Seat Size Code (SSC) 218.19-125
SKU: A0121863

Seco High Feed Milling Single Sided Insert 12.5 x 0.8 x 3.97mm MM4500 Grade (M07 Geometry) 218.19-125T-T3-M07,MM4500 Pack of 10

High Feed Milling Insert MM4500 Grade (M07 Geometry)

$326.04
