Max Dynamic Coupling Hub Straigh Blank Bore

  • Coupling hub straigh blank bore.

About Characteristics of MAX DYNAMIC Coupling

  • Facility protection for twirl and twist, impact and abrasion.
  • Very simple replacement and maintenance without oil and grease.
  • Very simple replacement without the separation of motor or connector on the related line due to it's simple structure.
  • Possible for the dissimilar connection and assembling with same hub.
  • Polyurethane based for having good water resistance, chemical resistance.
  • Highest flexible elasticity on run.
  • Less noise.

About Application

  • Agitator
  • Blower
  • Compressor
  • Conveyors
  • Cranes and Hoists
  • Elevators
  • Fans
  • Generators
  • Pump
  • Brewery and Distilling
  • Food Industry
  • Lumber Industry
  • Pulp and Paper Mill
  • Rubber Industry
  • Steel Industry
  • Textile Mills
  • Aggregate Processing Cement

Specifications

  • AIMS SKU A0151058
  • Weight (kg) 1.27
  • Max. Bore (mm) 34
  • Torque (kgf.m) 4.2
  • Max.rpm 7500
  • Power Rating (kw/rpm) 0.0043
  • A Out Dia 102
  • B Hub Length 32
  • C Max. Shaft Spacing 47
  • D Hub Dia 59
  • E Total Length In 83
  • F Total Length Out 111
  • C Min. Shaft Spacing 9
  • Type Coupling Hub
SKU: A0151058

Max Dynamic E-3 Coupling Hub Straigh Blank Bore 34mm
