Description

Metabo Table Saw - TS 254 M (610254190)

  • Compact mobile table saw with impressive cutting performance and high comfort for working.
  • Anti-twist tubular frame construction for the highest demands on the building site and during installations.
  • Cables and all add-on components for transport can be stored on the casing.
  • Powerful motor with electronic overload protection.
  • Motor brake for quick stop of the saw blade in 3 seconds.
  • Restart protection: prevents unintentional start-up after a power supply interruption.
  • Soft start for the long service life of motor and drive.
  • Precisely adjustable rip fence with double clamping and quick fastening.
  • Precise saw blade inclination via gear guide.
  • Automatic resetting to 0 – 45 ° after undercuts.
  • Easy saw blade change with spindle lock.
  • Splitting wedge can be lowered without tools for hidden cuts and transport.
  • Precise, extendable table width extension for extra large working surfaces.

Note

  • The machine shown may differ in equipment and technical details depending on the configuration.
  • Kindly pay attention to the content and product description.
  • Accessories are included only if listed in the contents.

Contents

  • Carbide saw blade with alternately bevel-ground tips (40 teeth)
  • Table Length Extension
  • Table width extension (right)
  • Push stick
  • Rip Fence
  • Mitre Fence

Technical Data

  • Maximum cutting height 90/45°: 80 / 48 mm // 3.15 / 1.87"
  • Maximum cutting width at rip fence: 520 mm / 20.46"
  • Saw blade: 254 x 30 mm // 10 x 1.181"
Characteristics

Dimensions 669 x 748 x 334 mm // 26.343 x 29.437 x 13.156 "
Working height 334 mm // 13.15 "
Cutting height 0 - 80 mm // 0 - 3.15 "
Maximum cutting height 90/45° 80 / 48 mm // 3.15 / 1.87 "
Maximum cutting width at rip fence 520 mm / 20.46 "
Maximum material width at mitre fence 195 mm / 7.68 "
No-load speed 4200 rpm
Cutting speed 56 m/s / 184 ft/s
Saw blade 254 x 30 mm // 10 x 1.181 "
Saw blade swivel range -1.5 - 46.5 °
Rated input power S1 100% 1500 W
Weight 24.4 kg / 54 lbs

Noise Emission
Sound pressure level 92 dB(A)
Sound power level (LwA) 105 dB(A)
Uncertainty of measurement K 3 dB(A)

Specifications

  • AIMS SKU A0175171
  • Brand Metabo
  • Model Number 610254190
  • Barcode Number 4061792180321
  • Type Table Saw
SKU: A0175171

Metabo Table Saw 669 x 748 x 334mm, TCT Blade 254 x 30mm - TS 254 M

Metabo Table Saw - TS 254 M (610254190)

$576.48
5/5 based on 1 review.
See all reviews

Calculate Shipping

Browse other products under

Power Saws & Accessories

Browse other products by

Metabo

Reviews

Metabo Table Saw Value for Money

"The machine is very well priced for what you get. It is solidly built, compact and easy to set up. Accessories are sturdy and accurate and the supplied blade is perfect for general use."

-
