Nachi 6209 Deep Groove Ball Bearing Open 45 x 85 x 19mm - NACHI

Description

Deep Groove Ball Bearing Open Type

Closure, open bearing (no seals or shields)
Deep Groove Ball Bearings use balls to maintain separation between the inner and out bearing races.
Deep Groove ball bearings are the most popular of all the ball bearing types because they are available in a wide variety of seal, shield and snap-ring arrangements.
Deep Groove ball bearings can sustain radial, axial, or composite loads and because of simple design, this bearing type can be produced to provide both high-running accuracy and high-speed operation.

Specifications

AIMS SKU A0106503

Brand NACHI

Model Number 6209/NACHI

Bore Diameter x Outer Diameter x Width (mm) 45 x 85 x 19

R (min) 1.1

Ra (max) 1

Factor Fo 14.1

Bore Diameter d (mm) 45

Width B (mm) 19

Da (min) 52

Da (max) 78

Basic Dynamic Load Rating Cr (n) 32500

Basic Static Load Rating Cor (n) 20500

Outer Diameter D (mm) 85
