Specifications
- AIMS SKU A0118509
- Brand Seco
- Model Number 03096562
- Barcode Number 96562030001008
- Designation SNMM190616-RR6 TP3501
- Type Turning Insert
- Insert Shape Code (SC) S
- Chipbreaker Programme RR6
- Theoretical Cutting Edge Length (L) mm 19.05
- Insert Included Angle (epsr) Deg 90.0 deg
- Fixing Hole Diameter (d1) Mm 7.9
- Clearance Angle Major (an) Deg 0.0 deg
- Inscribed Circle Diameter (IC) mm 19.05
- Insert Style SNMM
- Insert Grade Grade TP3501
- Insert Seat Size Code (SSC) 19
- Corner Radius (RE) mm 1.6
- Insert Thickness (S) mm 6.35
- Cutting Edge Effective Length (LE) mm 17.5
- Insert Hand (IH) Neutral
- Cutting Edge Count (CEDC) 4
- Grade Type Carbide CVD
- Grade TP3501
SKU: A0118509
Seco Turning Insert S Shape Code 6.35 x 1.6 x 19.05mm M Insert Type - RR6 Grade TP3501 ± 0.13/± 0.05mm Tolerance SNMM190616-RR6,TP3501 - Pack of 10
Turning Insert SNMM Insert Style - RR6 Grade TP3501
$500.50
