Seco Internal Turning Toolholder Steel Pin Lock

Turning Internal Toolholder (Steel - Pin Lock - P Type - V Insert Shape - 2.5mm Cutting Edge Length)

  • Steel with coolant passage.
  • V insert shape.
  • 0° ISCA (Insert Side Clearance Angles).
  • 2.5mm cutting edge length.
  • Pin lock assembly, (NL/PL tool holders).
  • P tool type, offset shank with 27.5° side and end cutting edge angle.

About Shank Toolholders and Boring Bars:

  • Seco’s incredibly diverse ranges of holders for general turning allow us to provide ideal solutions to your specific applications.
  • Whatever your material, set up, part requirements and machine capabilities, our expansive selection ensure a perfect match to your needs.
  • This wide offering of the easily applicable shank and boring bar tool holders adds another level of reliability and productivity to lathe machining.
  • The range of ISO and ANSI tool holders accommodates a comprehensive range of insert types, shapes, and sizes, also allowing the choice of several leading clamping methods.

Specifications

  • AIMS SKU A0114491
  • Brand Seco
  • Model Number 00015235
  • Barcode Number 15235000000107
  • Net Weight (kg) 1.08
  • Designation A16-PVPNL-2.5
  • Height Of Tool Holder Shank (H) mm 22
  • Insert Size Inscribed Circle Diameter (mm) 2.5
  • Functional Width (WF) mm 19.1
  • Inclination Angle (LAMS) -12.0 deg
  • Tool Cutting Edge Angle Code (KAPRC) P
  • Cutting Diameter Internal Minimum (DCINN) 33.02
  • Tool Type P Type
  • Functional Length (LF) 304.8mm
  • Shank Diameter (DMM) 25.4mm
  • Head Length (LH) mm 27.9
  • Tool Cutting Edge Angle (KAPR) 117.5 deg
  • Connection Text Workpiece Side (ctws) VN1304
  • Shank Width (b) mm 23
  • Direction Of Cutting (hand) Left
  • Connection Text Machine Side (CTMS) 25.4
  • Rake Angle Axial (gamp) -12.0 deg
  • Rake Angle Orthogonal (gamo) -3.0 deg
  • Type Turning Toolholder
  • Shank Type Cylindrical
  • Version (internal/external/both) Internal
  • Tool Holder Type Steel
  • Insert Clamping System (ICS) Pin Lock

Video

SKU: A0114491

Seco Internal Turning Toolholder Steel Pin Lock 304.8 x 25.4 x 33.02mm Left 117.5° V Insert Shape A16-PVPNL-2.5

Turning Internal Toolholder (Steel - Pin Lock - P Type)

$435.60
RRP $544.50
SAVE $108.90 (20%)
