Specifications

AIMS SKU A0114583
Brand Seco
Model Number 00054546
Barcode Number 54546000000103
Net Weight (kg) 0.007
Designation A05D-SCLDR04
Shank Diameter (DMM) 5
Functional Width (WF) mm 3
Cutting Edge Length (mm) 4
Inclination Angle (LAMS) -12.0 deg
Tool Cutting Edge Angle Code (KAPRC) L
Cutting Diameter Internal Minimum (DCINN) 5.5
Tool Type L Type
Functional Length (LF) 60
Height Of Tool Holder Shank (H) mm 4.7
Head Length (LH) mm 9.7
Tool Cutting Edge Angle (KAPR) 95.0 deg
Connection Text Workpiece Side (ctws) CD04T0
Shank Width (b) mm 5
Direction Of Cutting (hand) Right
Connection Text Machine Side (CTMS) 5
Rake Angle Orthogonal (gamo) 0.0 deg
• Type Turning Toolholder
• Shank Type Cylindrical
• Version (internal/external/both) Internal
• Tool Holder Type Steel
• Insert Clamping System (ICS) Screw Lock
