Specifications
- AIMS SKU A0013176
- Brand Sutton Tools
- Model Number T1570604
- Barcode Number 9311963516271
- Shank (mm) 4.5
- L1 (mm) 80
- Pitch (mm) 0.75
- L2 (mm) 14
- z 3
- Diameter (metric) MF6
- Drill Size (mm) 5.3
- L4 (mm) 6
- Square Size (mm) 3.4
- Group Code T157
- System of Measurement DIN374
- Thread Form ISO Metric Fine (MF)
- Material Premium Grade High Speed Steel (HSSE-V3)
- Finish Titanium Nitride (TiN)
- Lead ISO 2 / 6H Form B / 4.5 x P
- Application N (for normal and general purpose type materials)
- Shank Form Reduced Shank (with square drive)
- Max Cut Depth 3xD
- Tap Type Spiral Point (Gun)
SKU: A0013176
Sutton T1570604 Metric MF6 x 0.75 Spiral Point Tap - HSSE V3 TiN
Suttons Spiral Point (Gun) Taps - N
$92.50
