Specifications

AIMS SKU A0014859
Brand Sutton Tools
Model Number T3890300
Barcode Number 9311963043753
Pitch 0.5
d1 M3
l1 48
l2 11
l3 15
d2 3.15
sq 2.5
l4 5
z 3
drill ø 2.5
• Group Code T389
• Designation N
• System of Measurement ISO529
• Thread Form ISO Metric Coarse (M)
• Material High Speed Steel (HSS)
• Finish Bright
• Lead Taper
• Application N (for normal general purpose type materials)
• Max Cut Depth 1xD
• Tap Type Straight Flute
• Nut Tolerance ISO 2 / 6H LH
