Specifications

AIMS SKU A0015032
Brand Sutton Tools
Model Number T4031206
Barcode Number 9311963010878
Shank (mm) 9
L1 (mm) 89
Pitch (mm) 1.25
L2 (mm) 29
z 4
Diameter (metric) MF12
Drill Size (mm) 10.8
L4 (mm) 10
Sq 7.1
• Group Code T403
• System of Measurement ISO529
• Thread Form ISO Metric Fine (MF)
• Material High Speed Steel (HSS)
• Finish Bright
• Lead Bottoming
• Application N (for normal general purpose type materials)
• Shank Form Reinforced Shank (with square drive)
• Max Cut Depth 1xD
• Tap Type Straight Flute
• Nut Tolerance ISO 2 / 6H
