Specifications

AIMS SKU A0016151
Brand Sutton Tools
Model Number T9041270
Barcode Number 9311963011486
Diameter (inch) 1/2
TPI 20
Shank (mm) 9
L1 (mm) 89
L2 (mm) 29
z 4
Drill Size (mm) 11.5
L4 (mm) 10
Square Size (mm) 7.1
• Group Code T904
• System of Measurement ISO529
• Thread Form UNF
• Material High Speed Steel (HSS)
• Finish Bright
• Lead Taper/Intermediate/Bottoming
• Application N (for normal general purpose type materials)
• Shank Form Reinforced Shank (with square drive)
• Max Cut Depth 1xD
• Tap Type Straight Flute
• Nut Tolerance 2B
