Description

SY ASA Roller Chain Stainless Steel Duplex

Sugiyama Chain Manufacturing Co. is the only company in the world that supplies all of its standard chains with solid bushings and solid rollers.
This gives SY Chain a longer service life & a higher allowable maximum load.

Features

+30% Higher Fatigue Strength
- Higher safety factor is gained
- Downsizing to the smaller chain is possible in some applications
- Cost Savings
The longest chain life
- Significantly longer wear
- Up to 2-3 times longer wear life over curled bushings
- Reliable performance

All About Stainless Steel Chain

SS series stainless steel roller chains provide excellent corrosion protection against low or high temperature,acis alkali, moisture, scale, oil, and magnetism.
SS sereis stainless steel roller chains are manufactured in accordance with dimensions ANSI standards.
"SS" type roller chains are used in highly corrosive or extreme temperature environments.
All component parts of Sugiyama stainless steel roller chains are made of 304 stainless steel to achieve the utmost corrosion and temperature resistance.
Chain is rollerless. Dimension shown is bushing diameter.
Connecting links are "cotter" style for all sizes above 100 SS.
Stainless steel chains are not lubricated prior to delivery.
It is recommended to lubricate stainless steel chains before use except when the chain is exposed to water.
Stainless steel chains may suffer articulation problems in early stages if they are used without lubrication.
Takes account of a 35% reduction of fatigue strength when a single pitch offset link is used.

Introduction of SY New High Power New SSS Series Products

SSS series stainless steel roller chains with solid rollers.
Anti-magnetic of solid roller has superior permeability than the common curled roller.
High Power New SSS Chain use a specially treated pin and roller.
Extremely long life is engaged by this surface treatment.
SSS series chain life is more than 2 times longer than that of normal SS series Chain.
50% Higher Allowable Loads
