Description

TechTop’s TML series AC induction motors are ideally suited for all general purpose applications where starting torque performance and low weight are key factors.

The TechTop TML series electric motor's flexibility in mounting arrangements makes it a perfect fit for aluminium gearbox applications.

Motors up to 2.2kW are fitted with manual reset overload

Specifications

  • AIMS SKU A0098070
  • Brand TechTop
  • Model Number TA2A0187TML
  • Poles 2
  • Mounting Type Flange-Mounted
  • Base RPM 2710
  • IEC Frame Size 63 A
  • Shaft Diameter 11 mm
  • Mounting Position B14A
  • Group Code Techtop-TML-0.18kw
  • Type Single Phase
  • Material Aluminium
  • Nominal Rated Input Voltage 240 V
  • Rated Load (kW) 0.18
  • Rated Load (HP) 1/4
  • Series Techtop TML
  • AC Phase Single Phase
  • Current Type AC
SKU: A0098070

TechTop 0.18kW 1/4 HP Motor 240V 1 Phase 2 Pole, 2710 RPM, Flange Mount TA2A0187TML

240V Single Phase Cap Start/Cap Run Motor (TA2A0187TML)

$194.76
