Description

TechTop’s TAI aluminium series AC induction motors are suitable for all industrial applications where optimal design performance and low weight are key factors.

As standard, TechTop’s TAI series electric motors are fitted with detachable feet allowing for the motor feet to be repositioned to either side to produce a side mounted terminal box.

Minimum Energy Performance Standards (MEPS) Compliant

Specifications

  • AIMS SKU A0098583
  • Brand TechTop
  • Model Number TA4A0188TAI
  • Poles 4
  • Mounting Type Foot & Flange Mounted
  • Base RPM 1275
  • IEC Frame Size 63 B
  • Shaft Diameter 11 mm
  • Mounting Position B3,B14B
  • Group Code Techtop-TAI-0.18kw
  • Type Three Phase
  • Material Aluminium
  • Nominal Rated Input Voltage 415 V
  • Rated Load (kW) 0.18
  • Rated Load (HP) 1/4
  • Series Techtop TAI
  • AC Phase Three Phase
  • Current Type AC
SKU: A0098583

TechTop 0.18kW 1/4 HP Motor 415V 3 Phase 4 Pole, 1275 RPM, Foot & Flange TA4A0188TAI

415V Three Phase Aluminium Motor (TA4A0188TAI)

$124.42
5/5 based on 2 reviews.
See all reviews

Choose a different size/variant

Calculate Shipping

Resources

Browse other products under

415V Three Phase Motors

Browse other products by

TechTop

Reviews

Excellent after sales service

"1/4 hp motor arrived with broken mounting foot. AIMS arranged same day replacement from Distributor."

-

3 phase motor

"Awesome product and service"

-

Write a product review!

Help other AIMS Industrial Supplies users shop smarter by writing reviews for products you have purchased.

Write a product review
