TechTop 1.1kW 1 1/2 HP Motor 415V 3 Phase 6 Pole, 950 RPM, Foot & Flange TA6B011BTAI

Description

TechTop’s TAI aluminium series AC induction motors are suitable for all industrial applications where optimal design performance and low weight are key factors.

As standard, TechTop’s TAI series electric motors are fitted with detachable feet allowing for the motor feet to be repositioned to either side to produce a side mounted terminal box.

Minimum Energy Performance Standards (MEPS) Compliant

Specifications

AIMS SKU A0098842

Brand TechTop

Model Number TA6B011BTAI

Poles 6

Mounting Type Foot & Flange Mounted

Base RPM 950

IEC Frame Size 90 L

Shaft Diameter 24 mm

Mounting Position B3,B5R

Group Code Techtop-TAI-1.1kw
Type Three Phase
Material Aluminium
Nominal Rated Input Voltage 415 V
Rated Load (kW) 1.1
Rated Load (HP) 1 1/2
Series Techtop TAI
AC Phase Three Phase
Current Type AC
