Description

TechTop’s TAIB aluminium series AC induction motors are suitable for all industrial applications where optimal design performance and low weight are key factors.

TAIB braked motors are fitted with Intorq brand direct current brakes and are “fail to safe” design, as the brake will engage when the power is disconnected.

All TechTop TAIB series electric motors are fitted with an emergency hand release.

As standard, TechTop’s TAI series are fitted with detachable feet allowing for the motor feet to be repositioned to either side to produce a side mounted terminal box.

  • Aluminium Body
  • Wattage: 7.5kW
  • Poles: 4
  • Power: Three Phase (415V)
  • Mounting: Foot(B3)
  • Frame: 132 M
  • RPM: 1450
  • Shaft: 38mm
  • Full Load Amperage (FLA): 14.3A

Specifications

  • AIMS SKU A0098899
  • Brand TechTop
  • Model Number TA4B075 3TAIBHR
  • Type Three Phase with Brake
  • Material Aluminium
  • Nominal Rated Input Voltage 415 V
  • Poles 4
  • Rated Load (kW) 7.5
  • Rated Load (HP) 10
  • Series Techtop TAIB
  • AC Phase Three Phase
  • Current Type AC
  • Mounting Type Foot-Mounted
  • Base RPM 1450
  • IEC Frame Size 132 M
  • Shaft Diameter 38 mm
  • Mounting Position B3
SKU: A0098899 On Sale

TechTop 7.5kW 10 HP Motor 415V 3 Phase 4 Pole, 1450 RPM, Foot Mount TA4B075 3TAIBHR

415V Three Phase Aluminium Brake Motor (TA4B0753TAIBHR)

$2,569.31
$3,211.64
