Bossweld 6013 General Purpose Electrodes 2 mm, 2 kg | 110110
Available
The Bossweld 6013 General Purpose Electrodes are rutile-type electrodes for general fabrication work where weld appearance matters. They are classified AWS A5.1 E6013 (manufacturer-stated).
They give a smooth, stable arc, strike easily and leave a clean weld appearance. They suit thin material, including galvanised and painted steel, as well as structural steel, plate, sheet steel and tubular sections. They run on AC or DC and come in 2, 2.6 and 3.2 mm in 2 kg and 5 kg packs.
Where this product is used
- General welding and fabrication
- Galvanised steels
- Thin sheet and tubing
- Rural maintenance and fabrication
Features
- 6013 rutile general purpose electrodes
- Classified AWS A5.1 E6013 (manufacturer-stated)
- Smooth running and easy to strike
- Clean weld bead appearance
- Runs on AC or DC
- Flat, horizontal, vertical-up and overhead positions
Key specifications
| Specification | Detail |
|---|---|
| Type | Rutile general purpose stick electrode |
| AWS classification (manufacturer-stated) | AWS A5.1 E6013 |
| Current type | AC or DC |
| Diameters | 2, 2.6 and 3.2 mm |
| Pack weights | 2 kg and 5 kg |
| Welding positions | Flat, horizontal, vertical-up and overhead |
Options and part numbers
| Option | Part number | Diameter | Pack weight |
|---|---|---|---|
| 2 mm, 2 kg | 110110 | 2 mm | 2 kg |
| 2.6 mm, 2 kg | 110120 | 2.6 mm | 2 kg |
| 3.2 mm, 5 kg | 110130 | 3.2 mm | 5 kg |
| 2.6 mm, 5 kg | 110140 | 2.6 mm | 5 kg |
Selecting the right option
Choose the diameter to suit the material thickness and the amperage your machine delivers. If you are unsure which electrode suits your base metal and joint, contact AIMS with the metal and the joint you are making.
