1.1 kW Motor (1 1/2 HP) 415 V Three Phase Cast Iron Motor1

1.1 kW Motor (1 1/2 HP) 415 V Three Phase Cast Iron Motor

Description +

TechTop’s TCI cast iron series motors combine superior electrical characteristics, high quality design and the robust strength of cast iron. This AC induction motor is ideal for all industrial applications.

A unique feature of the TCI series electric motor is its multi-mount design up to 280 frame, allowing for the motor feet to be repositioned to either side to produce a side mounted terminal box.

Cast Iron Body
Wattage: 1.1kW
Poles: 2
Power: Three Phase (415V)
Mounting: Foot(B3)
Frame: 80 A
RPM: 2880
Shaft: 19mm
Full Load Amperage (FLA): 2.39A
Minimum Energy Performance Standards (MEPS) Compliant

Payment & Security

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

1.1 kW Motor (1 1/2 HP) 415 V Three Phase Cast Iron Motor

SKU: A0099291

Type: Three Phase

$376.61

Inc. GST

Buy It Now

Available

The 1.1 kW Motor (1 1/2 HP) 415 V Three Phase Cast Iron Motor by TechTop is a Three Phase electric motor with a robust cast iron body. It provides the full load amperage of 2.57A and is suitable for industrial applications.

FREE SHIPPING OVER $299*
RETURN AND EXCHANGE POLICY

Resources

Description +

A unique feature of the TCI series electric motor is its multi-mount design up to 280 frame, allowing for the motor feet to be repositioned to either side to produce a side mounted terminal box.

Cast Iron Body
Wattage: 1.1kW
Poles: 2
Power: Three Phase (415V)
Mounting: Foot(B3)
Frame: 80 A
RPM: 2880
Shaft: 19mm
Full Load Amperage (FLA): 2.39A
Minimum Energy Performance Standards (MEPS) Compliant
