Description
Description
TechTop’s TCI cast iron series motors combine superior electrical characteristics, high quality design and the robust strength of cast iron. This AC induction motor is ideal for all industrial applications.
A unique feature of the TCI series electric motor is its multi-mount design up to 280 frame, allowing for the motor feet to be repositioned to either side to produce a side mounted terminal box.
- Cast Iron Body
- Wattage: 1.5kW
- Poles: 2
- Power: Three Phase (415V)
- Mounting: Foot(B3)
- Frame: 90 S
- RPM: 2880
- Shaft: 24mm
- Full Load Amperage (FLA): 3.19A
- Minimum Energy Performance Standards (MEPS) Compliant
Specifications
Specifications
Applications
Applications
Features & Benefits
Features & Benefits
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
1.5 kW Motor (2 HP) 415 V Three Phase Cast Iron Motor
1.5 kW Motor (2 HP) 415 V Three Phase Cast Iron Motor
SKU: A0099000
Type: Three Phase
- Wide Range
- Reliable Services
- Proven Trust
Available
The 1.5 kW Motor (2 HP) 415 V Three Phase Cast Iron Motor by TechTop is a Three Phase with a cast iron body. It provides 1.5kW and is suitable for industrial applications.
- FREE SHIPPING OVER $299*
- RETURN AND EXCHANGE POLICY
Resources
Couldn't load pickup availability
Description
Description
TechTop’s TCI cast iron series motors combine superior electrical characteristics, high quality design and the robust strength of cast iron. This AC induction motor is ideal for all industrial applications.
A unique feature of the TCI series electric motor is its multi-mount design up to 280 frame, allowing for the motor feet to be repositioned to either side to produce a side mounted terminal box.
- Cast Iron Body
- Wattage: 1.5kW
- Poles: 2
- Power: Three Phase (415V)
- Mounting: Foot(B3)
- Frame: 90 S
- RPM: 2880
- Shaft: 24mm
- Full Load Amperage (FLA): 3.19A
- Minimum Energy Performance Standards (MEPS) Compliant
