BS 16B Taper Lock Sprocket, 38 Teeth, Duplex, 3030 Bush, Steel
Available
These steel duplex taper lock sprockets suit BS (ISO 606 B series) roller chain. The range covers 1 model across 1 chain size, 16B, at 38 teeth.
Each taper lock sprocket has a tapered bore that takes a taper lock bush. The bush is machined to your shaft size and keyway, and locks the sprocket on the shaft when its screws are tightened. Pitch diameter, outside diameter, hub diameter, total width and bush series come in each model.
Where this product is used
- Roller chain drives using BS chain
- Replacement sprockets for existing taper lock chain drives
- Conveyors and general machinery drives
- Drives where the sprocket needs to be removed and refitted
Features
- Taper lock hub, fitted with a separately sold taper lock bush
- Duplex sprocket for BS (ISO 606 B series) roller chain
- BS 16B, 1" (25.4mm) pitch, 38 teeth
- Steel construction
- Induction hardened teeth
- Bush series for each model: 3030
- Pitch diameter, outside diameter, hub diameter and width where available
Key specifications
| Specification | Detail |
|---|---|
| Product | Taper lock sprocket |
| Standard | BS (ISO 606 B series) |
| Strands | Duplex |
| Material | Steel |
| Tooth hardening | Induction hardened |
| Chain sizes | 16B |
| Number of teeth | 38 |
| Bore | Taper lock bush, sold separately |
| Bush series | 3030 |
Sizes available
| Chain | Pitch | Strands | Teeth | Bush series | Models |
|---|---|---|---|---|---|
| BS 16B | 1" (25.4mm) | Duplex | 38 | 3030 | 1 |
Choosing the right option
Choose the sprocket by chain size and number of teeth. The chain size must match your chain, and the tooth count sets the speed ratio. Then choose a taper lock bush of the series shown for that model, bored to your shaft diameter with a keyway. Check that the bush series covers your shaft diameter.
Dimensions are for reference.
Resources
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
BS 16B Taper Lock Sprocket, 38 Teeth, Duplex, 3030 Bush, Steel
SKU: A0148959 | Model: 16B-2-38TL-3030
Finer Power 16B-2-38TL-3030: BS 16B Taper Lock Sprocket. Material: Steel. Standard: BS (ISO 606 B series).
