Austsaw Panel Cutter (Specialty Saw Blade) - PSS3022

• Made from hardened tempered steel with double bevelled edges that fold edges as it cuts you will experience extreme cutting performance.

Specifications

• Diameter: 150mm
• Bore: 25
• Kerf/Plate: 3mm
• Teeth: 4 x Cutting Edges
• Max Speed: 5800 RPM

Designed for Cutting

• Cool Room Panel Products- Sandwich Panel, Cold Room Panel, Freezer Panel, and Thermal Panel.

Instructions For Use:

1. Set saw depth to cut 25-30% through the panel.
2. Mark and cut one side of panel then turn over to cut the opposite side.
3. Use hand saw to cut through remaining core if necessary.
4. Edges will be rolled to assist with panel jointing.
