Bondhus BD15716 1/2" Long Ball end L-Wrench
Available
These are Bondhus long ball end L-wrenches sold one size at a time, in inch sizes from 1/8" to 3/4". They suit maintenance fitters, machine assemblers and mechanics who need a single ball end key to replace a lost one or to stock the sizes they use most.
Bigger sizes have longer arms: the 1/8" key is 3.8" (95mm) long and the 3/4" key is 11.3" (286mm) long. Pick the size that matches your hex socket screw. The ball end has a rounded tip, so the key still engages when it is tilted. The ball end works at a 25 degree angle. For plain hex tips instead of a ball end, see the hex end tag-bar singles.
Where this product is used
- Turning socket head screws that are hard to reach straight on
- Replacing a lost or worn ball end key in the size you use most
- Working in hard to reach places with the key held at a 25 degree angle
Features
- Sizes in this range: 1/8", 9/64", 5/32", 3/16", 7/32", 1/4", 5/16", 3/8", 7/16", 1/2", 9/16", 5/8", 3/4"
- Length from 3.8" (95mm) at 1/8" to 11.3" (286mm) at 3/4"
- Ball end works at a 25 degree angle and funnels the tool into the screw quickly
- Chamfered tips help the tool seat fully in the screw head
- ProGuard finish is corrosion resistant and resists solvents
- Made from Protanium high torque steel, heat treated for more torque and longer tool life
- Long length series
Key specifications
| Specification | Detail |
|---|---|
| Brand | Bondhus |
| Range | Long ball end end L-wrench singles |
| Sizes in this range | 1/8", 9/64", 5/32", 3/16", 7/32", 1/4", 5/16", 3/8", 7/16", 1/2", 9/16", 5/8", 3/4" |
| Tip type | Ball end |
| Length series | Long |
| Shortest key | 3.8" (95mm) at 1/8" |
| Longest key | 11.3" (286mm) at 3/4" |
| Finish | ProGuard |
| Steel | Protanium high torque steel |
| Ball end working angle | 25 degrees |
| Packaging | Tagged and barcoded singles |
Choosing the right option
| Option | Part number | SKU |
|---|---|---|
| 1/2 | BD15716 | A0106014 |
| 1/4 | BD15712 | A0106010 |
| 1/8 | BD15707 | A0106005 |
| 3/4 | BD15719 | A0106017 |
| 3/8 | BD15714 | A0106012 |
| 3/16 | BD15710 | A0106008 |
| 5/8 | BD15718 | A0106016 |
| 5/16 | BD15713 | A0106011 |
| 5/32 | BD15709 | A0106007 |
| 7/16 | BD15715 | A0106013 |
| 7/32 | BD15711 | A0106009 |
| 9/16 | BD15717 | A0106015 |
| 9/64 | BD15708 | A0106006 |
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Bondhus Imperial Hex Key Ball End L-Wrench: 1/2
SKU: A0106014 | Model: BD15716
The BD15716 is the 1/2" long ball end L-wrench. It is 7.8" (198mm) long, with a 1.63" (41mm) short arm. The ball end works at a 25 degree angle. The next size up is 9/16", which is 9.0" (229mm) long.
