Bondhus 1/8" Ball End L-Wrench, ProGuard
Available
The Bondhus ball end L-wrench is an imperial hex key with a rounded ball end that goes into the screw at a 25° angle. That angle lets you turn the screw without lining the key up straight on, which funnels the tool in faster and works in hard-to-reach places. It comes in these sizes: 1/16", 5/64", 3/32", 7/64", 1/8", 9/64", 3/16", 7/32" and 5/16".
Bondhus makes it from Protanium High Torque Steel in the U.S.A. with a ProGuard finish for corrosion protection. The tips are chamfered for faster insertion and full engagement in the screw head. An L-wrench is a hex key bent into an L, with a long arm and a short arm. Here the long arm is 76mm to 152mm and the short arm 14mm to 32mm, depending on size. If you want the screw held on the tool, look at the Bondhus ProHold ball end L-wrench.
Where this product is used
- Turning hex socket screws at an angle, with a 25° ball end
- Reaching screws in hard-to-reach places
Features
- Ball end inserts into the screw at a 25° angle
- The ball end funnels the tool quickly into the screw
- The 25° angle allows natural hand and wrist movement
- Chamfered tips for faster insertion and full engagement in the screw head
- Long arm of 76mm to 152mm (3.0" to 6.0"), depending on size
- Short arm of 14mm to 32mm (0.56" to 1.25"), depending on size
- ProGuard finish gives corrosion protection
- Made in the U.S.A. from Protanium High Torque Steel
Key specifications
| Specification | Detail |
|---|---|
| Brand | Bondhus |
| Type | Ball end L-wrench |
| Hex sizes | 1/16", 5/64", 3/32", 7/64", 1/8", 9/64", 3/16", 7/32" and 5/16" (imperial) |
| Ball end angle | 25° |
| Long arm | 76mm to 152mm (3.0" to 6.0"), by size |
| Short arm | 14mm to 32mm (0.56" to 1.25"), by size |
| Tool tip | Chamfered ball end |
| Finish | ProGuard |
| Steel | Protanium High Torque Steel |
| Made in | U.S.A. |
Supplied with
- Sold by size (not a set)
Choosing the right option
| Option | Part number | SKU |
|---|---|---|
| 1/8 | BD12907 | A0105818 |
| 1/16 | BD12903 | A0105814 |
| 3/16 | BD12910 | A0105810 |
| 3/32 | BD12905 | A0105816 |
| 5/16 | BD12913 | A0105813 |
| 5/64 | BD12904 | A0105815 |
| 7/32 | BD12911 | A0105811 |
| 7/64 | BD12906 | A0105817 |
| 9/64 | BD12908 | A0105808 |
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Bondhus Imperial Hex Keys Ball End L-Wrench: 1/8
SKU: A0105818 | Model: BD12907
The 1/8" ball end L-wrench from Bondhus. The long arm is 95mm (3.8") and the short arm is 19mm (0.75"). The ball end goes into the screw at a 25° angle and the tip is chamfered for faster insertion. It has a ProGuard finish.
