Bondhus 1.5mm Ball End L-Wrench BD12950
Available
The Bondhus ball end L-wrench is an Allen key with a rounded tip, made for metric hex socket screws from 1.5mm to 12mm. The ball end goes into the screw at up to a 25 degree angle, so you can turn a screw without lining the key up straight. That helps in hard to reach places.
The ball end tip is chamfered for faster insertion, and the finish is ProGuard for corrosion protection. These are the long series, so the long arm gives good reach. If you want the screw to stay on the key, choose the ProHold version. If you want a plain hex tip, choose the hex end L-wrench.
Where this product is used
- Reaching hex socket screws at an angle in machinery and equipment
- Maintenance and assembly where the screw is hard to reach
- Workshop and tool box stock for fitters and mechanics
Features
- Ball end inserts into the screw at a 25 degree angle
- Natural hand and wrist movement at that angle
- Works in hard to reach places
- Chamfered tips for faster insertion and full engagement in the screw head
- ProGuard finish for corrosion protection
- Metric sizes 1.5mm to 12mm, from 77mm to 220mm overall
- Its steel is up to 20% stronger, with more torque and higher wear resistance than standard steel.
Key specifications
| Specification | Detail |
|---|---|
| Brand | Bondhus |
| Range | Ball end L-wrench, metric |
| Length series | Long |
| Hex sizes | 1.5mm to 12mm |
| Tip | Ball end, 25 degree working angle |
| Overall length range | 77mm to 220mm |
| Finish | ProGuard |
Supplied with
- One ball end L-wrench in the size you choose
Choosing the right option
| Option | Part number | SKU |
|---|---|---|
| 1.5 | BD12950 | A0105819 |
| 2 | BD12952 | A0105820 |
| 2.5 | BD12954 | A0105821 |
| 3 | BD12956 | A0105822 |
| 4 | BD12960 | A0105823 |
| 5 | BD12964 | A0105824 |
| 6 | BD12968 | A0105825 |
| 8 | BD12972 | A0105826 |
| 10 | BD12976 | A0105827 |
| 12 | BD12980 | A0105828 |
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Bondhus Metric Hex Keys Ball End L-Wrench: 1.5
SKU: A0105819 | Model: BD12950
The 1.5mm ball end key. It is 77mm overall with a 14mm arm, the short end that goes into the screw. The ball end goes into the screw at up to a 25 degree angle, so you can turn it without lining the key up straight.
