Chrome Alloy Tap and Button Die Set Metric Coarse

• Chrome Alloy Intermediate Taps and 1" Button Dies.

Coarse and Fine

• The angle of a thread is 60°.
• The crest is flat and the thread has clearance at the root allowing the external thread and internal thread to engage well.
• A larger root radius and lower thread height enable easy screw thread processing and increase thread screw strength.
• The major diameter of external thread and pitch is specified by a simple numerical value (most commonly measured in millimeters).

Intermidiate Taps

• Intermediate Taps have a lead of four threads and are used in most general purpose applications to cut a thread true to a pre-drilled pilot hole.

Contents

Title
Qty
3 x 0.5mm MC Intermediate Chrome Tap
1
4 x 0.7mm MC Intermediate Chrome Tap
1
5 x 0.8mm MC Intermediate Chrome Tap
1
6 x 1mm MC Intermediate Chrome Tap
1
8 x 1.25mm MC Intermediate Chrome Tap
1
10 x 1.5mm MC Intermediate Chrome Tap
1
12 x 1.75mm MC Intermediate Chrome Tap
1
3 x 0.5mm MC 1" Chrome Button Die
1
4 x 0.7mm MC 1" Chrome Button Die
1
5 x 0.8mm MC 1" Chrome Button Die
1
6 x 1mm MC 1" Chrome Button Die
1
8 x 1.25mm MC 1" Chrome Button Die
1
10 x 1.5mm MC 1" Chrome Button Die
1
12 x 1.75mm MC 1" Chrome Button Die
1
Quick Change Ratchet T Pattern Tap Wrench
1
Die Holder for 4220-S2 Set
1
