Bordo 13mm HSS Morse Taper Shank (MTS) Bridge Reamer
Available
The Bordo HSS Morse Taper Shank (MTS) Bridge Reamer is part of Bordo's Australian range of machining tools, built for reliable performance in trade and industrial applications.
Key Specifications
| Size (mm) | 13 |
|---|---|
| Flute Type | Spiral |
| Flute (mm) | 105 |
| Taper Length L3 (mm) | 42 |
| Overall Length (OAL) mm | 199 |
| MTS No. | 2 |
| Min Dia. D1 (mm) | 8.8 |
| Max Dia. D2 (mm) | 13 |
Product Features
- Bridge reamers should be run at half the R.P.M. suggested for a corresponding twist drill size
- HSS Morse Taper Shank Tapered Spiral Flute Bridge Reamer
- Bridge reamers are used to create an aligned hole in a structural steel assembly. These reamers enlarge and align holes for rivets and bolts in structural steel members such as I-beams, angles, channels, and plates
- All tools are constructed with left-hand spiral and right-hand cut
- The left-hand spiral eliminates the tendency of the reamer to pull itself into the hole
Resources
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Bordo HSS Morse Taper Shank (MTS) Bridge Reamer: 13
SKU: A0199071 | Model: 6335-13.00
This is the 13mm size option of the Bordo HSS Morse Taper Shank (MTS) Bridge Reamer. Key details for this option: flute type Spiral, taper length 42mm.
Bordo HSS Morse Taper Shank (MTS) Bridge Reamer
HSS Morse Taper Shank Tapered Spiral Flute Bridge Reamer
Bridge reamers are used to create an aligned hole in a structural steel assembly.
These reamers enlarge and align holes for rivets and bolts in structural steel members such as I-beams, angles, channels, and plates.
The reamer is tapered for approximately half its FL allowing the reamer to enter out-of-line holes often encountered in structural work.
All tools are constructed with left-hand spiral and right-hand cut.
The left-hand spiral eliminates the tendency of the reamer to pull itself into the hole.
In large structural assemblies, the holes are generally punched undersize and then reamed when in position.
The idea is that the holes most likely will not line up within about 1/8" when a fabricated 50 foot beam or column is finally put into place.
Coolant or cutting tool lubricant should be utilitised when possible.
Benefits include better finishes, superior tool life and the ability to increase speeds and feeds.
Bridge reamers should be run at half the R.P.M. suggested for a corresponding twist drill size.
