Dixon Hex nipple, 1/4" (8mm)

This Dixon hex nipple has an external BSP thread on each end with a hex section in the middle, and is made from galvanised malleable iron. It joins two female ports of the same size. It comes in 11 sizes from 1/4" to 4".

The galvanised malleable iron BSP fittings are ISO 5922 malleable cast iron, hot dip galvanised to ISO 1461, with ISO 7-1 pipe threads, for general low-pressure air and water at a working pressure of 150 PSI (about 10 bar).

Where this product is used

• Joining two female BSP fittings, valves or ports in air and water pipework
• Short make-up connections between a valve, union and tee without cutting pipe

Features

• Hex nipple, male BSP both ends
• End connection: Male BSP both ends
• Body: ISO 5922 malleable cast iron, hot dip galvanised to ISO 1461
• Working pressure: 150 PSI (about 10 bar), for general low-pressure air and water
• Sizes: 1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", 4"

Key specifications

Choosing the right option

The thread size is the same on both ends. BSP threads do not mate with NPT or metric threads, so confirm the thread on every mating part before you order. The hex lets you use a spanner and not a pipe wrench. The 1/8" size is available only in the stainless range.
