Dixon Reducing hex nipple, 1/4 x 1/8
Available
This Dixon reducing hex nipple has an external BSP thread on each end, with a larger thread on one end and a smaller one on the other, and a hex section in the middle. It is made from 316 stainless steel (CF8M). There are 18 size combinations, from 1/4" x 1/8" to 4" x 3".
The 316 stainless steel BSP fittings are CF8M (316) stainless steel to ASTM A351, Class 150 lbs, with ISO 7-1 pipe threads, rated at 300 PSI (about 21 bar) for low-pressure service that includes chemical and corrosive environments as well as standard air and water.
Where this product is used
- Stepping down from a larger female port to a smaller one in stainless pipework, in chemical, corrosive, air and water service
- Fitting a smaller valve, gauge or instrument to a larger outlet without a separate reducer
Features
- Reducing hex nipple, male BSP both ends
- End connection: Male BSP both ends, different sizes
- Body: CF8M (316 stainless steel) to ASTM A351, Class 150 lbs
- Working pressure: 300 PSI (about 21 bar), for low-pressure service including chemical and corrosive environments
- Sizes: 1/4" x 1/8" to 4" x 3" (18 combinations)
Key specifications
| Specification | Detail |
|---|---|
| Brand | Dixon |
| End connection | Male BSP both ends, different sizes |
| Body material | CF8M (316 stainless steel), ASTM A351 |
| Thread standard | ISO 7-1 pipe threads (BSP) |
| Design | Class 150 lbs, generally in accordance with AS3673, with slight variations where the manufacturer's dimensions are used |
| Working pressure | 300 PSI (about 21 bar) |
| Application | Low-pressure service, including chemical and corrosive environments, and standard air and water |
Choosing the right option
Read the size as large x small: for example 1/2" x 1/4" has a 1/2" thread on one end and a 1/4" thread on the other. Both ends are male, so each side screws into a female port. If you need a male thread on one side and a female on the other, use a reducing bush. BSP threads do not mate with NPT or metric threads, so confirm the thread on every mating part before you order.
Related Dixon fittings: Dixon Hex Nipple BSP 316 Stainless Steel, Dixon Screwed Reducing Hex Bush Male x Female BSP 316 Stainless Steel and Dixon Screwed Reducing Hex Nipple BSP Galvanised Malleable Iron.
| Option | Part number | SKU |
|---|---|---|
| 1/4 x 1/8 | SS16N00806 | A0071257 |
| 1/2 x 1/4 | SS16N01508 | A0071259 |
| 1/2 x 3/8 | SS16N01510 | A0071260 |
| 1 x 1/2 | SS16N02515 | A0071262 |
| 1 x 3/4 | SS16N02520 | A0071263 |
| 1-1/4 x 1 | SS16N03225 | A0071264 |
| 1-1/2 x 1 | SS16N04025 | A0071265 |
| 1-1/2 x 1-1/4 | SS16N04032 | A0071266 |
| 2 x 1 | SS16N05025 | A0071267 |
| 2 x 1-1/4 | SS16N05032 | A0071268 |
| 2 x 1-1/2 | SS16N05040 | A0071269 |
| 2-1/2 x 2 | SS16N06550 | A0071270 |
| 3/8 x 1/4 | SS16N01008 | A0071258 |
| 3/4 x 1/2 | SS16N02015 | A0071261 |
| 3 x 2 | SS16N08050 | A0071271 |
| 3 x 2-1/2 | SS16N08065 | A0071272 |
| 4 x 2 | SS16N10050 | A0071274 |
| 4 x 3 | SS16N10080 | A0071276 |
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Dixon Screwed Reducing Hex Nipple BSP 316 Stainless Steel: 1/4 x 1/8
SKU: A0071257 | Model: SS16N00806
Dixon SS16N00806: Reducing hex nipple, 1/4 x 1/8.
