Dixon Stainless Steel EZ Boss-Lock Cam & Groove Type D Coupler x Female BSP

Applications

• The Dixon Cam & Groove coupling is a reliable quick connect coupling for use on a hose; pipe; tubing and tanks conveying a wide variety of liquids; dry bulk materials and vapors including cooling water; fuels; chemicals; cosmetics; food products; adhesives; dyes; pharmaceuticals; pellets and much more.

Use

• Designed for use with liquids

Features

• Resistant to accidental disconnection when dragged. The release lever opens in the direction opposite to the cam arm; so movements that tend to open the release lever also tend to close the cam arm.
• Rotating action helps keep the locking device free of debris.
• Designed to protect critical parts from impact and to withstand rugged use.

How it works

• To make a connection; simply slide the adapter into the coupler and with normal hand pressure; press the cam levers down.
• Uncoupling is as quick and simple as coupling. Just lift the cam arms and remove the adapter.
• No more fumbling with clamps; wire; clips or pins; just close the handles and the locking mechanism is engaged.
• Extremely easy to open; the releaser lever is under your thumb when you want to open the fitting; ergonomic.

Note

• If the rotating lever is not flush with the handle; it is not properly engaged.

Safety notes

• Under no circumstances should cam and groove couplings be used for compressed air or steam service!
• Under no circumstances should the EZ Boss-Lock cam arms be used on any fitting not specifically designed for their use.
• Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70°F/21°C with a standard seal installed.
