Gates For Longer Belt Service Life

The Gates belt tension gauge enables accurate measurement of belt tension during installation and maintenance. Correct belt tension is critical to drive performance — too loose causes slippage and belt wear, too tight overloads bearings and shortens both belt and bearing life. Gates publish specific tension values for every belt section and drive configuration.

Where this product is used

Gates belt tension gauges ensure drives are set to the correct tension — a key factor in belt life and drive efficiency. Typical uses include:

• Belt tensioning and verification during scheduled drive maintenance and belt replacement
• Commissioning of new drives to confirm correct tension before start-up, reducing early-life belt failures
• Preventive maintenance programmes across fleet, mining and manufacturing facilities

Key specifications

Selecting the right option

The sonic tension meter (Gates 550C) is the most accurate method and works on any belt type by measuring vibration frequency — preferred for critical or high-value drives. The barrel-type spring gauges (15 kg and 30 kg) provide a practical field measurement for general industrial use. The Krikit gauge is a compact, low-cost option for light-duty V-belt applications. Match the gauge capacity to your expected belt tension range.
