Goliath BSW Thread Ring Gauge Go 1/8" x 40 TPI
Out of stock
The Goliath BSW Thread Ring Gauge comes in several options that differ in diameter, threads per and ring gauge type. Go ring gauges and No-Go ring gauges are separate products. Durable high precision gauge. Go of thread ring gauge controls the workpiece's external thread's pitch diameter and minor diameter's maximum physical size.
Where this product is used
- Used in engineering, quality control, manufacturing and construction
Features
- BSW - British Standard Whitworth
- Standard tolerance Medium
- Supplied with manufacturer inspection certificate
Key specifications
| Specification | Detail |
|---|---|
| Brand | Goliath |
| Type | Ring Gauge |
| Gauge type | No-Go |
Choosing the right option
Each option has its own part number.
The lead time is approximately 6 to 8 weeks. A calibration certificate is included. A lead time applies to all gauges. These goods are made to order and are non-refundable.
| Option | Part number | SKU |
|---|---|---|
| 1/8 / Go | 3028-1/8R | A0175247 |
| 1/4 / Go | 3028-1/4R | A0175250 |
| 1/2 / Go | 3028-1/2R | A0175254 |
| 1 / Go | 3028-1R | A0175259 |
| 1-1/8 / Go | 3028-1.1/8R | A0175260 |
| 1-1/4 / Go | 3028-1.1/4R | A0175261 |
| 1-1/2 / Go | 3028-1.1/2R | A0175262 |
| 1-3/4 / Go | 3028-1.3/4R | A0175263 |
| 1/8 / No-Go | 3028-1/8R-NG | A0175264 |
| 1/4 / No-Go | 3028-1/4R-NG | A0175267 |
| 1/2 / No-Go | 3028-1/2R-NG | A0175271 |
| 1 / No-Go | 3028-1R-NG | A0175276 |
| 1-1/8 / No-Go | 3028-1.1/8R-NG | A0175277 |
| 1-1/4 / No-Go | 3028-1.1/4R-NG | A0175278 |
| 1-1/2 / No-Go | 3028-1.1/2R-NG | A0175279 |
| 1-3/4 / No-Go | 3028-1.3/4R-NG | A0175280 |
| 3/16 / Go | 3028-3/16R | A0175249 |
| 3/8 / Go | 3028-3/8R | A0175252 |
| 3/4 / Go | 3028-3/4R | A0175257 |
| 3/16 / No-Go | 3028-3/16R-NG | A0175266 |
| 3/8 / No-Go | 3028-3/8R-NG | A0175269 |
| 3/4 / No-Go | 3028-3/4R-NG | A0175274 |
| 5/32 / Go | 3028-5/32R | A0175248 |
| 5/16 / Go | 3028-5/16R | A0175251 |
| 5/8 / Go | 3028-5/8R | A0175256 |
| 5/32 / No-Go | 3028-5/32R-NG | A0175265 |
| 5/16 / No-Go | 3028-5/16R-NG | A0175268 |
| 5/8 / No-Go | 3028-5/8R-NG | A0175273 |
| 7/16 / Go | 3028-7/16R | A0175253 |
| 7/8 / Go | 3028-7/8R | A0175258 |
| 7/16 / No-Go | 3028-7/16R-NG | A0175270 |
| 7/8 / No-Go | 3028-7/8R-NG | A0175275 |
| 9/16 / Go | 3028-9/16R | A0175255 |
| 9/16 / No-Go | 3028-9/16R-NG | A0175272 |
Resources
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Goliath BSW Thread Ring Gauge: 1/8 / Go
SKU: A0175247 | Model: 3028-1/8R
Goliath BSW Thread Ring Gauge Go 1/8" x 40 TPI, part number 3028-1/8R. Diameter 1/8", threads per 40" and thread type BSW. BSW - British Standard Whitworth.
