Goliath Metric Fine Thread Ring Gauge Go 8 x 1mm
Out of stock
The Goliath Metric Fine Thread Ring Gauge Go comes in several options that differ in diameter and pitch. Go ring gauges and No-Go ring gauges are separate products. Durable high precision gauge. Go of thread ring gauge controls the workpiece's external thread's pitch diameter and minor diameter's maximum physical size.
Where this product is used
- Used in engineering, quality control, manufacturing and construction
Features
- Standard tolerance 6G
- Supplied with manufacturer inspection certificate
Key specifications
| Specification | Detail |
|---|---|
| Brand | Goliath |
| Type | Ring Gauge |
| Gauge type | Go |
Choosing the right option
Each option has its own part number.
The lead time is approximately 6 to 8 weeks. A calibration certificate is included. A lead time applies to all gauges. These goods are made to order and are non-refundable.
| Option | Part number | SKU |
|---|---|---|
| 8 / 1mm | 3021-8.00R | A0174752 |
| 10 / 1mm | 3022-10.00R | A0174753 |
| 10 / 1.25mm | 3021-10.00R | A0174754 |
| 12 / 1.25mm | 3022-12.00R | A0174755 |
| 12 / 1.5mm | 3021-12.00R | A0174756 |
| 14 / 1.25mm | 3022-14.00R | A0174757 |
| 14 / 1.5mm | 3021-14.00R | A0174758 |
| 16 / 1.5mm | 3023-16.00R | A0174759 |
| 18 / 1.5mm | 3022-18.00R | A0174760 |
| 20 / 1.5mm | 3023-20.00R | A0174761 |
| 22 / 1.5mm | 3021-22.00R | A0174762 |
| 24 / 2mm | 3021-24.00R | A0174763 |
Resources
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Goliath Metric Fine Thread Ring Gauge Go: 8 / 1 mm
SKU: A0174752 | Model: 3021-8.00R
Goliath Metric Fine Thread Ring Gauge Go 8 x 1mm, part number 3021-8.00R. Diameter 8mm, pitch 1mm and thread profile Fine. Standard tolerance 6G.
