Goliath 1/4" x 20 UNC Fluteless HSS-Co5 Tap B11CG
Available
Goliath is an Australian precision cutting tool brand supplying HSS taps, threading dies, tap and die sets, thread gauges, and key steel to engineering, manufacturing, maintenance, and toolmaking operations across Australia. This page covers the Goliath UNC Fluteless HSS-Co5 Tap, available in 10 diameter (inch) options: 1/4, 1/2, 3/8, No. 4, No. 5, 5/16, No. 6, 7/16 and 2 more.
Goliath UNC tap and die sets cover the Unified National Coarse thread range for threading applications in American-standard machinery, equipment, and fastener repair.
Where this product is used
Goliath unc tap and die set products are used across engineering workshops, production machining, and industrial maintenance programs.
- Cutting Unified National Coarse threads for American-standard machinery, equipment, and fastener work.
- Maintenance and repair of American-standard equipment and imported machinery with UNC fixings.
- Workshop threading in industries using American or US-export equipment.
Key specifications
| Specification | Detail |
|---|---|
| Material Grade | HSS-Co5 Cobalt |
Selecting the right option
Select the UNC set that covers your required size range — Goliath offers sets from No. 2 to 3/4" UNC. HSS grade suits hand and light machine threading on steel, aluminium, and non-ferrous materials. For production work on individual UNC sizes, consider individual Goliath machine taps.
Resources
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Goliath UNC Fluteless HSS-Co5 Tap: 1/4
SKU: A0196001 | Model: B11CG
Diameter (inch) 1/4. Goliath UNC Fluteless HSS-Co5 Tap
HSS-Co (Cobalt) Bright Finish UNC Fluteless Machine Tap.
HSS Fluteless (Roll Form) Taps.
Fluteless taps are also referred to as "Roll Form" or "Thread Flow" taps.
Unlike standard taps, fluteless taps create internal threads by pressure deformation, rather than by material removal.
As a result, no chips are formed as no material is removed.
The thread is formed by the tap in the ductile material creating threads that have a smoother surface and greater tensile strength under dynamic stress than cut threads.
It is essential to use a high quality lubricating fluid when using fluteless taps.
Materials with a minimum elongation of 5% and a tensile strength no greater than 1,000 N/mm2 are suitable for thread forming.
The Unified National Coarse thread form was introduced in 1948 as an attempt to standardise thread forms in the USA, Canada and the UK.
The thread profile of UNC is the same as for metric threads and is described in the JIS B0206 standard.
The thread is described by its major diameter and the number of threads per inch of length (TPI).
This thread series is commonly used in the mass production of bolts, screws, and nuts.
It is used for threading into lower tensile strength materials (bronze, brass, aluminium, and plastics) to obtain the best resistance to stripping of the internal thread.
It is also used on quick assembly or disassembly or if corrosion or slight damage is possible.
Manufactured from HSS this fluteless tap is designed for use in medium tensile materials and is for hand or general machine use.
IMPORTANT - Fluteless Taps use different tapping drill sizes than standard taps.
