Goliath UNC Thread Ring Gauge Go 5G x 40 TPI
Out of stock
The Goliath UNC Thread Ring Gauge comes in several options that differ in diameter inch, threads per, ring gauge type and diameter. Go ring gauges and No-Go ring gauges are separate products. Durable high precision gauge. Go of thread ring gauge controls the workpiece's external thread's pitch diameter and minor diameter's maximum physical size.
Where this product is used
- Used in engineering, quality control, manufacturing and construction
Features
- UNC - Unified National Coarse
- Standard tolerance 2A
- Supplied with manufacturer inspection certificate
Key specifications
| Specification | Detail |
|---|---|
| Brand | Goliath |
| Type | Ring Gauge |
| Gauge type | No-Go |
Choosing the right option
Each option has its own part number.
The lead time is 6 to 8 weeks from receipt of the order. A calibration certificate is included. A lead time applies to all gauges. These goods are made to order and are non-refundable.
| Option | Part number | SKU |
|---|---|---|
| 5G / Go | 3032-5GR | A0175329 |
| 5G / No-Go | 3032-5GR-NG | A0175347 |
| 6G / Go | 3032-6GR | A0175330 |
| 6G / No-Go | 3032-6GR-NG | A0175348 |
| 8G / Go | 3032-8GR | A0175331 |
| 8G / No-Go | 3032-8GR-NG | A0175349 |
| 10G / Go | 3032-10GR | A0175332 |
| 10G / No-Go | 3032-10GR-NG | A0175350 |
| 12G / Go | 3032-12GR | A0175333 |
| 12G / No-Go | 3032-12GR-NG | A0175351 |
| 1/4 / Go | 3032-1/4R | A0175334 |
| 1/2 / Go | 3032-1/2R | A0175338 |
| 1 / Go | 3032-1R | A0175343 |
| 1-1/8 / Go | 3032-1.1/8R | A0175344 |
| 1-1/4 / Go | 3032-1.1/4R | A0175345 |
| 1-1/2 / Go | 3032-1.1/2R | A0175346 |
| 1/4 / No-Go | 3032-1/4R-NG | A0175352 |
| 1/2 / No-Go | 3032-1/2R-NG | A0175356 |
| 1 / No-Go | 3032-1R-NG | A0175361 |
| 1-1/8 / No-Go | 3032-1.1/8R-NG | A0175362 |
| 1-1/4 / No-Go | 3032-1.1/4R-NG | A0175363 |
| 1-1/2 / No-Go | 3032-1.1/2R-NG | A0175364 |
| 3/8 / Go | 3032-3/8R | A0175336 |
| 3/4 / Go | 3032-3/4R | A0175341 |
| 3/8 / No-Go | 3032-3/8R-NG | A0175354 |
| 3/4 / No-Go | 3032-3/4R-NG | A0175359 |
| 5/16 / Go | 3032-5/16R | A0175335 |
| 5/8 / Go | 3032-5/8R | A0175340 |
| 5/16 / No-Go | 3032-5/16R-NG | A0175353 |
| 5/8 / No-Go | 3032-5/8R-NG | A0175358 |
| 7/16 / Go | 3032-7/16R | A0175337 |
| 7/8 / Go | 3032-7/8R | A0175342 |
| 7/16 / No-Go | 3032-7/16R-NG | A0175355 |
| 7/8 / No-Go | 3032-7/8R-NG | A0175360 |
| 9/16 / Go | 3032-9/16R | A0175339 |
| 9/16 / No-Go | 3032-9/16R-NG | A0175357 |
Resources
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Goliath UNC Thread Ring Gauge: 5G / Go
SKU: A0175329 | Model: 3032-5GR
Goliath UNC Thread Ring Gauge Go 5G x 40 TPI, part number 3032-5GR. Diameter inch 5G, threads per 40" and thread type UNC. UNC - Unified National Coarse.
