Bordo 2mm HSS Cobalt TiAlN Coated Blue Band Stub Drill Bit
Available
The Bordo HSS Cobalt TiAlN Coated Blue Band Stub Drill Bit - 2051 is part of Bordo's Australian drill bit range, engineered for reliable performance in trade and industrial drilling applications.
Key Specifications
| Diameter (mm) | 2 |
|---|---|
| Surface Finish | Violet / Grey |
| Cutting Speed m/min Titanium-Pure | 20-32 |
| Stainless Steel-Austenitic | 10-15 m/min (Cutting Speed) |
| Cutting Speed m/min Titianium-Alloy | 6-12 |
| Cutting Speed m/min Nickel-Pure | 10 -15 |
| Stainless Steel-Martensitic, F | 12-18 m/min (Cutting Speed) |
| Stainless Steel-Free Cutting | 12-22 m/min (Cutting Speed) |
| Flute Type | 35 ° Helix |
| Flute Length (mm) | 12 |
| Overall Length (OL) mm | 38 |
| Feed per Revolution (mm) | 0.07 |
| Sub Brand | Colour Band |
| Type of Point | Multi Faceted |
Product Features
- DIN1897
- Bordo Metric Blue Band HSS-Co TiAlN Coated Stub Drills for Stainless Steel
- Multi-faceted point with two helical flutes with 35 degrees of helix angle
Resources
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
HSS Cobalt TiAlN Coated Blue Band Stub Drill Bit - 2051: 2
SKU: A0193306 | Model: 2051-2.00
This is the 2mm diameter option of the HSS Cobalt TiAlN Coated Blue Band Stub Drill Bit - 2051. Key details for this option: flute type 35° Helix, type of point Multi Faceted, flute length 12mm.
Bordo HSS Cobalt TiAlN Coated Blue Band Stub Drill Bit - 2051
DIN1897.
HSS Cobalt TiAlN Coated Blue Band Stub Drill.
Bordo Metric Blue Band HSS-Co TiAlN Coated Stub Drills for Stainless Steel.
Multi-faceted point with two helical flutes with 35 degrees of helix angle.
The machining of stainless steels is difficult due to its work hardening properties, toughness and poor thermal conductivity, which places high demands on the cutting tools.
They are designed primarily for machining operations in lathes (screw machines) but can also be used in manual hand held drills.
The Blue Band - Stainless Steel - Series has been specifically designed to suit these difficult machining requirements.
TiAlN coating increases tool surface hardness to 87Rc.
For machining materials with Hardness < 350 HB : Tensile Strength <1250 N/mm².
The multi faceted point was specifically developed to enable higher load carrying capacity and to enhance feed rates during the machining of difficult materials such as stainless steel.
About Drill Bit Surface Treatment
Violet / Grey - TiAlN (Titanium Aluminium Nitride - TiAlN)
A violet/grey finish with a higher hardness than both TiN and TiCN coating utilises aluminium in the coating which imparts greater oxidation stability.
This stability is a result of a very thin film (of Aluminium Oxide) which is formed on the surface of the TiAlN.
This film is self repairing which leads to increased tool service life.
This high performance coating is able to withstand much higher temperatures which allows increased speeds and feeds and semi-dry machining operations.
TiAlN coating is especially useful when machining cast iron and tough steels.
About Stainless Steel Blue Band
The machining of stainless steels is difficult due to its work hardening properties, toughness and poor thermal conductivity, which places high demands on the cutting tools.
The Blue Band Series has been specifically designed to suit these difficult machining requirements.
TiAlN coating increases tool surface hardness to 87Rc.
For machining materials with Hardness <350 HB : Tensile Strength <1250 N/mm².
