KCM Stainless Steel BS Roller Chain Connecting Link Duplex
Available
KCM connecting links join the ends of a length of BS stainless steel duplex roller chain into a continuous loop. Match the link to the KCM chain with the same chain number, strand count and series. Made entirely of SUS304 (18Cr-8Ni) austenitic stainless steel.
Where this product is used
- Corrosive environments
- Hot environments and areas that need clean chain
- Wet and washdown areas where carbon steel would corrode
Features
- Matched to the KCM chain of the same number and series
- Joins the chain ends into a continuous loop
- Made entirely of SUS304 (18Cr-8Ni) austenitic stainless steel
- Operating range -20 to +400°C
- Slightly magnetic as a result of cold manufacturing
Key specifications
| Specification | Detail |
|---|---|
| Brand | KCM |
| Product type | Connecting Link (Full Link) |
| Standard | BS (ISO 606) |
| Series | Stainless Steel (SS) |
| Strands | Duplex |
| Component | Connecting link |
| Material | SUS304 (18Cr-8Ni) stainless steel |
| Chain sizes | 06BSS, 08BSS and 10BSS (3) |
| Pitch | 9.525 to 15.875mm |
| Supplied as | Individual links |
Choosing the right option
For BS chain the number is the pitch in sixteenths of an inch: 08B is 8/16" (1/2"), 12B is 12/16" (3/4"), 16B is 1". The figure after the dash is the number of strands.
Choose stainless steel chain where corrosion, heat or cleanliness rules out carbon steel. A strengthened AS stainless chain is also available, with a maximum allowable load 1.5 times that of standard SS.
Related KCM products: KCM Stainless Steel BS Roller Chain Duplex 06BSS, 08BSS and 10BSS, 10 ft Box, KCM Stainless Steel BS Roller Chain Offset Link (Half Link) Duplex 06BSS and 08BSS.
| Option | SKU |
|---|---|
| 06B | A0066898 |
| 08B | A0066900 |
| 10B | A0157934 |
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
KCM Stainless Steel BS Roller Chain Connecting Link Duplex 06BSS-10BSS: 06B
SKU: A0066898 | Model: 06B-2SS-CL/KCM
KCM 06BSS-2 BS stainless steel duplex roller chain connecting link, 3/8" pitch.
