Ko-Ken 14405A 12-point impact socket, 1"

Ko-Ken 14405A is a 12-point impact socket with a 1/2" square drive. Sizes run from 3/8 to 1-1/2". Lengths are 38 to 53mm.

Where this product is used

• Turning inch nuts and bolts with a 1/2" drive impact wrench
• Workshop, maintenance and assembly work on exposed fasteners
• General workshop and maintenance fastening

Features

• 1/2" square drive
• 12-point (bi-hexagon) opening
• Retaining pin and O-ring or C-ring parts for each size
• Length: 38 to 53mm

Key specifications

Choosing the right option

Match the 1/2" square drive to your impact wrench, then choose the size that fits the fastener. Dimension labels: D1, D2 and H. Retaining parts for these sockets: pin A41 with O-ring B41 or C-ring C41; pin A42 with O-ring B42 or C-ring C42. The part for each size is shown in its specifications. Select impact sockets only for electric or air impact wrenches, wear safety goggles when using nut runners or impact wrenches, never substitute a hand socket for an impact socket, and replace sockets with cracked walls, battered points or other marks of wear.

Related Ko-Ken products: Ko-Ken 14400A 6-Point Impact Socket, Inch Sizes, 1/2" Drive, Ko-Ken 14300A 6-Point Deep Impact Socket, Inch Sizes, 1/2" Drive, Ko-Ken 14405M 12-Point Impact Socket, Metric Sizes, 1/2" Drive, Ko-Ken 14012M-60 Impact Inhex Socket, Metric Sizes, 1/2" Drive.
