Ko-Ken KO12300M06 6-Point Deep Impact Socket, 6 mm, 1/4 in Drive
Available
The Ko-Ken 12300M is a 6-point deep impact socket with a 1/4 in square drive. (manufacturer-stated)
Sizes run from 6 to 14 mm.
Length is 48 mm. (manufacturer-stated)
Each model is listed in the table below with its specifications.
Where this product is used
- Turning metric nuts and bolts with a 1/4 in drive impact wrench
- Nuts on long studs and recessed fasteners where a standard socket will not reach
- General workshop and maintenance fastening
Features
- 1/4 in square drive (manufacturer-stated)
- 6-point (hexagon) opening (manufacturer-stated)
- Deep body (manufacturer-stated)
- Listed in the Impact Sockets section of the catalogue (manufacturer-stated)
- Retaining pin and O-ring or C-ring parts listed in the catalogue for each size (manufacturer-stated)
Common specifications
| Specification | Detail |
|---|---|
| Drive | 1/4 in (manufacturer-stated) |
| Opening | 6-point (manufacturer-stated) |
| Socket type | Deep (manufacturer-stated) |
| Length | 48 mm (manufacturer-stated) |
| Retaining parts | Pin A21, O-ring B21 (manufacturer-stated) |
Key specifications
| Model | Size | Weight |
|---|---|---|
| KO12300M06 | 6 mm | 26 g (manufacturer-stated) |
| KO12300M07 | 7 mm | 30 g (manufacturer-stated) |
| KO12300M08 | 8 mm | 32 g (manufacturer-stated) |
| KO12300M10 | 10 mm | 34 g (manufacturer-stated) |
| KO12300M12 | 12 mm | 49 g (manufacturer-stated) |
| KO12300M13 | 13 mm | 52 g (manufacturer-stated) |
| KO12300M14 | 14 mm | 57 g (manufacturer-stated) |
Weights are manufacturer-stated (Ko-ken catalogue 2025-26).
Selecting the right option
Match the 1/4 in square drive to your impact wrench, then choose the size that fits the fastener. Choose the deep series when a standard socket will not reach the fastener, for example a nut on a long stud. Dimensions are shown with the labels used in the catalogue table (D1, D2, H1 and H2). The catalogue footnotes list these retaining parts for the sockets: pin A21 with O-ring B21. The part for each size is shown in its specifications. The catalogue lists the pins, O-rings and C-rings as separate packs (pages 270 and 271) and does not say whether any are supplied with the socket. (manufacturer-stated) The catalogue's safety notes say to select impact sockets only for electric or air impact wrenches, to wear safety goggles when using nut runners or impact wrenches, never to substitute a hand socket for an impact socket, and to replace sockets with cracked walls, battered points or other marks of wear. (manufacturer-stated)
