Ko-Ken KO16305M14 12-Point Deep Impact Socket, 14 mm, 3/4 in Drive
Available
The Ko-Ken 16305M is a 12-point deep impact socket with a 3/4 in square drive. (manufacturer-stated)
Sizes run from 14 to 50 mm.
Length is 100 mm. (manufacturer-stated)
Each model is listed in the table below with its specifications.
Where this product is used
- Turning metric nuts and bolts with a 3/4 in drive impact wrench
- Nuts on long studs and recessed fasteners where a standard socket will not reach
- General workshop and maintenance fastening
Features
- 3/4 in square drive (manufacturer-stated)
- 12-point (bi-hexagon) opening (manufacturer-stated)
- Deep body (manufacturer-stated)
- Listed in the Impact Sockets section of the catalogue (manufacturer-stated)
- Retaining pin and O-ring or C-ring parts listed in the catalogue for each size (manufacturer-stated)
Common specifications
| Specification | Detail |
|---|---|
| Drive | 3/4 in (manufacturer-stated) |
| Opening | 12-point (manufacturer-stated) |
| Socket type | Deep (manufacturer-stated) |
| Length | 100 mm (manufacturer-stated) |
Key specifications
| Model | Size | Weight | Pin / O-ring / C-ring |
|---|---|---|---|
| KO16305M14 | 14 mm | 500 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M16 | 16 mm | 522 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M17 | 17 mm | 544 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M18 | 18 mm | 600 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M19 | 19 mm | 655 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M21 | 21 mm | 700 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M22 | 22 mm | 700 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M23 | 23 mm | 720 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M24 | 24 mm | 715 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M26 | 26 mm | 760 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M27 | 27 mm | 765 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M28 | 28 mm | 800 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M29 | 29 mm | 835 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M30 | 30 mm | 840 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M32 | 32 mm | 875 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M33 | 33 mm | 920 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M34 | 34 mm | 950 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M35 | 35 mm | 980 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M36 | 36 mm | 960 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M38 | 38 mm | 990 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M41 | 41 mm | 1,120 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M46 | 46 mm | 1,305 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16305M50 | 50 mm | 1,469 g (manufacturer-stated) | A62 / B62 / - |
Weights and retaining part codes are manufacturer-stated (Ko-ken catalogue 2025-26).
Selecting the right option
Match the 3/4 in square drive to your impact wrench, then choose the size that fits the fastener. Choose the deep series when a standard socket will not reach the fastener, for example a nut on a long stud. Dimensions are shown with the labels used in the catalogue table (D1, D2, H1 and H2). The catalogue footnotes list these retaining parts for the sockets: pin A61 with O-ring B61 or C-ring C61; pin A62 with O-ring B62. The part for each size is shown in its specifications. The catalogue lists the pins, O-rings and C-rings as separate packs (pages 270 and 271) and does not say whether any are supplied with the socket. (manufacturer-stated) The catalogue's safety notes say to select impact sockets only for electric or air impact wrenches, to wear safety goggles when using nut runners or impact wrenches, never to substitute a hand socket for an impact socket, and to replace sockets with cracked walls, battered points or other marks of wear. (manufacturer-stated)
