Ko-Ken KO16300A32 6-Point Deep Impact Socket, 1 in, 3/4 in Drive
Available
The Ko-Ken 16300A is a 6-point deep impact socket with a 3/4 in square drive. (manufacturer-stated)
Sizes run from 3/4 to 2 in.
Length is 100 mm. (manufacturer-stated)
Each model is listed in the table below with its specifications.
Where this product is used
- Turning inch nuts and bolts with a 3/4 in drive impact wrench
- Nuts on long studs and recessed fasteners where a standard socket will not reach
- General workshop and maintenance fastening
Features
- 3/4 in square drive (manufacturer-stated)
- 6-point (hexagon) opening (manufacturer-stated)
- Deep body (manufacturer-stated)
- Listed in the Impact Sockets section of the catalogue (manufacturer-stated)
- Retaining pin and O-ring or C-ring parts listed in the catalogue for each size (manufacturer-stated)
Common specifications
| Specification | Detail |
|---|---|
| Drive | 3/4 in (manufacturer-stated) |
| Opening | 6-point (manufacturer-stated) |
| Socket type | Deep (manufacturer-stated) |
| Length | 100 mm (manufacturer-stated) |
Key specifications
| Model | Size | Weight | Pin / O-ring / C-ring |
|---|---|---|---|
| KO16300A24 | 3/4 in | 655 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A26 | 13/16 in | 700 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A28 | 7/8 in | 700 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A30 | 15/16 in | 705 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A32 | 1 in | 715 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A34 | 1-1/16 in | 765 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A36 | 1-1/8 in | 835 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A38 | 1-3/16 in | 840 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A40 | 1-1/4 in | 875 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A42 | 1-5/16 in | 950 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A44 | 1-3/8 in | 980 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A46 | 1-7/16 in | 970 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A48 | 1-1/2 in | 990 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A50 | 1-9/16 in | 1,060 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A52 | 1-5/8 in | 1,120 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A54 | 1-11/16 in | 1,200 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A56 | 1-3/4 in | 1,284 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A58 | 1-13/16 in | 1,305 g (manufacturer-stated) | A61 / B61 / C61 |
| KO16300A60 | 1-7/8 in | 1,561 g (manufacturer-stated) | A62 / B62 / - |
| KO16300A64 | 2 in | 1,516 g (manufacturer-stated) | A62 / B62 / - |
Weights and retaining part codes are manufacturer-stated (Ko-ken catalogue 2025-26).
Selecting the right option
Match the 3/4 in square drive to your impact wrench, then choose the size that fits the fastener. Choose the deep series when a standard socket will not reach the fastener, for example a nut on a long stud. Dimensions are shown with the labels used in the catalogue table (D1, D2, H1 and H2). The catalogue footnotes list these retaining parts for the sockets: pin A61 with O-ring B61 or C-ring C61; pin A62 with O-ring B62. The part for each size is shown in its specifications. The catalogue lists the pins, O-rings and C-rings as separate packs (pages 270 and 271) and does not say whether any are supplied with the socket. (manufacturer-stated) The catalogue's safety notes say to select impact sockets only for electric or air impact wrenches, to wear safety goggles when using nut runners or impact wrenches, never to substitute a hand socket for an impact socket, and to replace sockets with cracked walls, battered points or other marks of wear. (manufacturer-stated)
Related products
Related Ko-Ken products: Ko-Ken 16400A 6-Point Impact Socket, Inch Sizes, 3/4 in Drive, Ko-Ken 16300M 6-Point Deep Impact Socket, Metric Sizes, 3/4 in Drive, Ko-Ken 16405A 12-Point Impact Socket, Inch Sizes, 3/4 in Drive, Ko-Ken 16107-22 Impact Hex Bit Socket, Metric Sizes, 3/4 in Drive, Ko-Ken Impact Socket Spare Pin and Ko-Ken 1600C-10 C-Ring Retaining Clip Kit, 10 Clips, 3/4 in Drive.
