Ko-Ken KO183H35M05 Impact Hex Bit, 5 mm, 7/16 in Hex Input

The Ko-Ken 183H-35 is an impact hex bit with a 7/16 in hex input end. (manufacturer-stated)

Hex sizes are 5, 6, 8 and 10 mm.

Length is 35 mm. (manufacturer-stated)

Each model is listed in the table below with its specifications.

Where this product is used

• Driving hex socket screws with an impact bit holder
• Machinery and equipment maintenance where hex socket fasteners are used
• Workshop and maintenance work

Features

• 7/16 in hex input end (manufacturer-stated)
• Hex bit with a hex tip in millimetre sizes (manufacturer-stated)
• DIN 3126 E11.2 and ISO 1173 E11.2 marked on the drawing (manufacturer-stated)
• Listed in the Impact Sockets section of the catalogue (manufacturer-stated)

Common specifications

Key specifications

Weights are manufacturer-stated (Ko-ken catalogue 2025-26).

Selecting the right option

Choose the hex size to match the screw, and use the bit with an impact bit holder that takes a 7/16 in hex input. The manufacturer prints DIN 3126 E11.2 and ISO 1173 E11.2 on the drawing of the 7/16 in hex input end. (manufacturer-stated) A catalogue footnote says the items it marks have a larger output size than the 7/16 in input hex drive, so their maximum output torque rating is less than standards. Check the marked sizes in the Ko-ken catalogue before using at high torque. (manufacturer-stated) The catalogue's safety notes say to select impact sockets only for electric or air impact wrenches, to wear safety goggles when using nut runners or impact wrenches, never to substitute a hand socket for an impact socket, and to replace sockets with cracked walls, battered points or other marks of wear. (manufacturer-stated)
